Model | JC45L | JC60L | |
Operating load (kg) | 700 | 850 | |
Max Speed(km/h) | 12 | 12 | |
Rated flux (L/min) | 62.5 | 75 | |
Tire(track) model | 10-16.5 | 12-16.5 | |
Rated power (Kw) | 37 | 45 | |
Fuel tank capacity (L) | 60 | 60 | |
Self weight bucket (kg) | 2600 | 3000 | |
Bucket capacity (m3) | 0.4 | 0.45 | |
A | Overall operating height (mm) | 3670 | 3690 |
B | Height to bucket hinge pin (mm) | 2900 | 2920 |
C | Height to top of cab (mm) | 2030 | 2050 |
D | Height to bottom of level bucket(mm) | 2733 | 2753 |
E | Overall length ithout bucket(mm) | 2450 | 2630 |
F | Overall length with bucket(mm) | 3200 | 3380 |
G | Dumping angle at maximum height(° ) | 40 | 40 |
H | Dumping height(mm) | 2380 | 2400 |
I | Dumping reach(mm) | 700 | 750 |
J | Rollback o bucket on ground(° ) | 30 | 30 |
K | Rollback of bucket at full height(° ) | 104 | 104 |
L | Wheelbase(mm) | 991 | 991 |
M | Ground clearance(mm) | 185 | 205 |
N | Angleof departure(° ) | 20 | 20 |
O | Front turning radins without bucket(mm) | 1168 | 1198 |
P | Front tuning radius(mm) | 1958 | 1958 |
Q | Rear tuning radius(mm) | 1630 | 1728 |
R | Rear axle to bumper (mm) | 1108 | 1208 |
S | Tread width,enterline to centerline (mm) | 1450 | 1500 |
T | Width (mm) | 1720 | 1800 |
U | Bucket width (mm) | 1740 | 1820 |
